AVMATRIX TS3019 User Manual

4
7
PGM7 red Tally7
20
PVW6 green Tally6
8
PGM6 red Tally6
21
PVW5 green Tally5
9
PGM5 red Tally5
22
PVW4 green Tally4
10
PGM4 red Tally4
23
PVW3 green Tally3
11
PGM3 red Tally3
24
PVW2 green Tally2
12
PGM2 red Tally2
25
PVW1 green Tally1
13
PGM1 red Tally1
3.SPECIFICATION
TALLY
BOX
PARAMETERS
Connections
1×GPIO，1×RS-232，1×RS-485，1×USB type-c
Number of Lamps
Support up to 16 tally lamps (12 LED lamp)
Wireless Distance
Transmission up to 200m (line-of-sight)
Wireless Connectivity
433MHz
Wired Connectivity
RS-485 serial connection
Application Support
Video switchers with GPIO-tally interface such as
AVMATRIX ,Roland, SONY, NewTek, Panasonic,
DataVideo, or tally converter box with GPIO such as
BMD's GPI and tally interface
Power
Working Voltage: 5V, Power Consumption: ≤ 0.2W
TALLY
LAMP
PARAMETERS
Connections
1×USB Type-c,1×RS-485,TALLY OUT
Power supply
5V USB power supply or 18650 lithium battery
(optional) power supply
Brightness
Support 4-level brightness
Battery Operating Time
up to 9 hours (depending on battery capacity & lamp
brightness & usage environment)
Power
Working Voltage: 5V; Power Consumption: ≤2.5W;
Battery Charging Current: 5V 1A
Mouting Hole
1/4 inch hotshoe hole
Dimension (LWD)
Tally box: 104*75.5*24.5mm
Tally lamp: 98.5*65*26.5 mm

AVMATRIX TS3019 Specifications

General

Brand	AVMATRIX
Model	TS3019
Category	Industrial Equipment
Language	English
