Ayre AX-5 User Manual

Numbers and
Specifications
Power Output 125 watts per channel continuous into 8 ohms
250 watts per channel continuous into 4 ohms
Maximum Input Level 8 V rms – unbalanced inputs
16 V rms – balanced inputs
Input Impedance 1 MΩ – unbalanced inputs
2 MΩ – balanced inputs (1 MΩ per phase)
XLR Input Polarity Pin 1 = Ground
Pin 2 = Non-inverting (Positive)
Pin 3 = Inverting (Negative)
Gain 32 dB (maximum, at volume level of “
46”)
Frequency Response DC - 250 kHz
Power Consumption 48 watts in low-current consumption mode
230 watts in operating mode, no signal
Dimensions 17-¼" W x 18-¾" D x 4-¾" H
44 cm x 48 cm x 12 cm
Weight 46 pounds
21 kg
28
