Ayre KX-R User Manual

Setup and
Configuration
Due to the large number of available inputs (eight) on the
KX-R, activating only the desired inputs allows for simpler
operation of the unit.
Only the active inputs will be included in the list of available
source components. If no inputs are activated, the preamplifier
will automatically enter the setup mode when AC power is
applied.
Activating Inputs
The desired inputs are activated simply by naming them. When
AC power is first applied to the unit, the front panel will briefly
display “
Ayre KX-R” and “FW Rev. x” in sequence, where “FW Rev.
x
” indicates “Firmware Revision x”, where “x” is a letter from
“
A” to “Z”.
Assuming that none of the inputs have yet been configured, the
unit will then automatically enter the setup mode. The front
panel will then briefly display “
Setup Mode”.
After automatically entering the setup mode, the front panel
will display “
Set1 Unused”.
7
Ayre KX-R
FW Rev. x
Setup Mode
Set1 Unused
