1. Operating Elements
1. Operating Elements
12 3 4 514156
7
8
13 12
11
10
9
1 Push-button switch for battery test
2 Selector switch 0 - 5 kV or 0 - 25 kV
3 Voltage regulator with 0-locking
4 Range selector switch for current indication
5 Operating switch with timer and discharge unit
6 High voltage output with controlling contact
7 Connector for protective earth cable
8 Mains connector with power selector and fuses
9 Connectors for external battery (12 V)
10 Connector for current range plotter
11 H.V. control lamp
12 µA - meter
13 kV - meter with indication for battery test
Option: Guard connection
14 Operating mode switch for current measurement
15 Terminal for current measurement
