P.991:2 absolute value encoder (Becker-Antriebe GmbH)
Parameter Input Function
Terminals P.4E0 SE 1 Optoelectronic safety edge or electric safety edge
(specified at the initial operation stage)
P.4F0: 3.00 SE 2 Wicket door resistor 8k2 ohm
P.510: 10.00 FE 1 Slack rope NC
P.520: 22.00 FE 2 Light barrier 1
P.530: 13.00 FE 3 Drive command STOP
P.540: 12.00 FE 4 Drive command CLOSE
P.550: 11.02 FE 5 Drive command OPEN
P.560: 16.01 FE 6 Selection switch partial opening
P.570: 14.02 FE 7 Drive command sequence OPEN / STOP / CLOSE
P.580: 17.01 FE 8 Selection switch automatic reclosing
P.992:1 two-way traffic control with M1 expansion board
Parameter Input Function
Terminals P.590: 11.02 FE 9 Drive command OPEN
P.594: 0 FE 9 Inside
P.5A0: 11.02 FE 10 Drive command OPEN
P.5A4: 1 FE 10 Outside
P.710: 13 REL1 Stop light red inside
P.720: 14 REL2 Stop light green inside
P.740: 15 REL4 Stop light red outside
P.750: 16 REL5 Stop light green outside
P.800: 1 BDC-M1 expansion board active
P.892: 1 Display two-way traffic control parameters
P.992:2 two-way traffic control with M2 expansion board
Parameter Input Function
Terminals P.650: 11.02 FE 5 BDC-M2 Drive command OPEN
P.654: 0 FE 5 BDC-M2 Inside
P.660: 11.02 FE 6 BDC-M2 Drive command OPEN
P.664: 1 FE 6 BDC-M2 Outside
P.760: 13 REL1 BDC-M2 Stop light red inside
P.770: 14 REL2 BDC-M2 Stop light green inside
P.780: 15 REL3 BDC-M2 Stop light red outside
P.790: 16 REL4 BDC-M2 Stop light green outside
P.801: 1 BDC-M2 expansion board active
P.892: 1 Display two-way traffic control parameters
33
