Disposal
The crossed-out bin symbol on the product indicates that the device is subject
to mandatory disposal separate from household waste. This product must be
handed over to a collection point for electrical and electronic equipment at the
end of its service life.
The packaging material must be disposed of properly.
Technical data
Rated voltage 230-240 V AC / 50-60 Hz
Degree of protection IP44
Permissible ambient temperature -25 to +55°C
Maximum emitted transmission out-
put
≤ 25 mW
Radio frequency 868.3 MHz
The maximum transmitter range on and in the building is up to 25m, and up to
350m in the open.
What to do if...?
Problem Remedy
The drive is not functioning.
The transmission pilot light on the
sensor lights up.
Reduce the distance from the re-
ceiver.
Program the sensor in the receiver.
Automatic drive commands are not
executed.
Set the slide switch of the hand-held/
wall transmitter to “ ”.
Wait until the rain sensor has dried.
20-en
