Behringer C-1 User Manual

6
STUDIO CONDENSER MICROPHONE C-1 User Manual
Specications6.
Transducer type condenser, 16 mm
Polar pattern cardioid
Connection: gold-plated balanced XLR connector
Open circuit sensitivity -33 ± 2 dBV (0 dBV = 1 V/Pa)
Frequency response 40 Hz - 20 kHz
Max. SPL (1% THD @ 1 kHz) 136 dB
Nominal impedance 100 Ω
Load impedance >1 kΩ
Mains Voltage / Fuse
Supply voltage +36 - 52 V
Supply current 2.5 mA
Physical/Weight
Dimensions Ø shaft: 54 mm
length: 169 mm
Weight approx. 0.45 kg

Behringer C-1 Specifications

General

Type	Studio microphone
Microphone frequency	40 - 20000 Hz
Microphone direction type	Cardioid
Microphone input impedance	100 Ω
XLR out	Yes
Device interface	XLR-3
Connectivity technology	Wired
Operating voltage	52 V
Power consumption	2.5 mA
Number of products included	1 pc(s)
Depth (imperial)	7 \
Height (imperial)	2.12 \
Product color	-

Weight and Dimensions

Depth	180 mm
Height	54 mm
Microphone weight	420 g
Microphone dimensions (D x H)	54 x 180 mm
