Behringer VIRTUALIZER PRO DSP1000P User Manual

30
6. APPENDIX
6.1 Parameter overview
Nr. EFFECT VARIATION EDIT A EDIT B
ENGINE L
ENGINE R
ENGINE L ENGINE R
1
CATHEDRAL Reverb Time Diffusion Early Reflections High Multiply
2
PLATE
Reverb Time Pre Delay Stereo Width High Multiply
3
SMALL HALL Reverb Time Diffusion Early Reflections Stereo Width
4
ROOM Reverb Time Pre Delay Wall Damp
5
STUDIO Reverb Time Pre Delay Early Reflections
Wall Damp
6
CONCERT Reverb Time Pre Delay Early Reflections Diffusion
7
STAGE Reverb Time Diffusion Liveliness Stereo Width
8
VOCAL Reverb Time Pre Delay Early Reflections High Mulitiply
9
PERCUSSION
Reverb Time Diffusion High Frequency Decay
10
DELAY Del. Coarse Delay Time Delay Time Feedback Feedback
11
ECHO Del. Coarse Delay Time Delay Time Feedback Feedback
12
GATED REVERB Gate Time Density Gate Threshold
13
REVERSE REVERB
Gate Time Pre Delay Gate Threshold
14
VOCAL DISTORTION Distortion Type Delay Time (x 10 ms) Delay Mix
15
ROTARY SPEAKER
Rotary Type Horn Speed Rotor Speed
16
VOCODER Vocoder Type Vocoder Distortion Vocoder Sens
17
PITCH Cent
Cent
Semi Tone Semi Tone
18
FLANGER Mod. Frequency Mod. Depth Mod. Depth Mod. Feedback Mod. Feedback
19
CHORUS
Mod. Frequency Mod. Delay Mod. Delay Mod. Depth
Mod. Depth
20
TREMOLO & DELAY
Mod. Frequency Mod. Depth Del. Time (x 10 ms) Panning Delay Feedback
21
DELAY & REVERB
Del. Mix Del. Time (x 10 ms) Reverb Time Feedback Reverb Mix
22
PITCH & REVERB Cent Reverb Time Semi Tone Reverb Mix
23
FLANGER & REVERB
Mod. Frequency Mod. Depth Reverb Time Mod. Feedback Reverb Mix
24
CHORUS & REVERB
Mod. Frequency Mod. Delay Reverb Time Mod. Depth Reverb Mix
25
PITCH / REVERB Cent Reverb Time Semi Tone High Multiply
26
FLANGER / REVERB
Mod. Frequency Mod. Depth Reverb Time Mod. Feedback High Multiply
27
CHORUS / REVERB
Mod. Frequency Mod. Delay Reverb Time Mod. Depth High Multiply
28
TREMOLO / REVERB Mod. Frequency Del. Time (x 10 ms) Reverb Time Delay Feedback High Multiply
29
DELAY / REVERB
Del. Time (x 10 ms) Reverb Time Delay Feedback High Multiply
30
PITCH / ECHO Cent Del. Time (x 10 ms) Semi Tone Delay Feedback
31
FLANGER / ECHO
Mod. Frequency Mod. Depth Del. Time (x 10 ms) Mod. Feedback Delay Feedback
32
CHORUS / ECHO
Mod. Frequency Mod. Delay Del. Time (x 10 ms) Mod. Depth Delay Feedback
Tab. 6.1: Parameter overview of the different effect types
6. APPENDIX
