XENYX X2442USB
X2222USB / X1832USB
X1622USB / X1222USB
X1204USB / 1204USB
1204USB
Perfect for a small live-performance
mixer, as well as home-based recording
setup, the 1204USB provides four mono
channels with premium XENYX mic
preamps, neo-classic 3-band British-style
EQ and two stereo input channels.
Far from being a “bare-bones” mixer,
all mono channels feature our “one
knob” studio-grade compressor and two
Aux Sends (one each pre- and post-fader).
Two stereo Aux Returns are included
for use with external FX modules.
The built-in USB audio interface provides
bi-directional transfer of signals between
the mixer and computer.
Onboard FX
processor (not
on 1204USB),
16 presets,
two parameter
controls
Aux Sends
1 & 2
Stereo Aux
Returns 1 & 2
Phones/
CTRL RM
source mixing
matrix
Phones/CTRL
RM level control
8-tier VU meter
with +48 V and
Power LEDs
VU meter
mode switch
Alt 3-4
faders
Main Mix
faders
XLR mic input
with XENYX
preamp
¼" balanced/
unbalanced
input
Low Cut lter
removes
unwanted
infrasonics
Gain control
adjusts input
signal level
Compressor
knob adjusts
compression
eect on channel
High EQ
±15 dB,
centered @
12 kHz
Mid EQ ±15
dB, centered @
2.5 kHz
Low EQ
±15 dB,
centered @
80 Hz
Aux Sends
for monitors
and FX
Pan control
adjusts position
of signal in
stereo image
Mute/Alt 3-4
switch removes
signal from
Main Mix,
sends signal to
Alt 3-4 bus
Channel fader
adjusts signal
level in Main Mix,
Mute & Clip LEDs,
channel Solo switch
1204USB/X1204USB Front Panel
