4
OVERVIEW
Technical Specifications
Upstream Ports (1)
Downstream Ports (7)
Per-port Voltage DC +5V
Per Port Current 500mA (max)
Power Mode Self-Powered
Operating Temperature 5ºC ~ 40ºC
Storage Temperature -20ºC ~ 60ºs
Enclosure ABS
Power Supply
Output: DC 6V, 4A
Plug Size: 3.5mm (outer) 1.0mm (center)
Plug Polarity: Center Positive
Main Power LED Color Definitions:
Off Not Operational
Red Operational
Port Status LED Color Definitions:
Off Over Current Condition
Green Fully Operational
P74387ea_F5U237ea_uk 09-09-2003 10:07 Page 4
