3
Product Detail
SLAVE INPUT
DB25 Daisy-chain port
MASTER INPUT
SLAVE OUTPUT
DB25 Daisy-chain port
DC power
jack
DIP switches
Optional
serial mouse
connector
CONSOLE
connectors
Keyboard
connector
PS/2 mouse
connector
VGA monitor
connector
PC PORT
connectors
Serial mouse
output
Keyboard
output
PS/2 mouse
output
VGA signal output
FRONT PANEL
REAR PANEL
Current Active Port
LED Indicators
Current Active Bank
LED Indicators
Bank Select/
Scan Button
Port Select
Button
P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 3
