TRK 502/ 502X
50
LUBRICATION POINTS
Appropriate lubrication is important to keep every part of your motorcycle in normal running and lengthen its
working life and to ensure safe driving. Lubricate your motorcycle after you have driven it for a long mileage or the
vehicle is wet due to raining or washing. Detail lubrication points are shown in the gure below:
Motorcycle lubricant
Lubricant grease
1. Rear brake pedal shaft
2. Side stand and its spring
3. Throttle cable
4. Pivot of front brake lever
5. Pivot of clutch lever
ADJUSTMENT OF VALVE CLEARANCE
Check and adjust the valve clearance when the engine is cold.
The Standard Valve Clearance: Intake Valve: 0.15-0.19mm, Exhaust Valve: 0.20-0.25mm
INSPECTION BEFORE DRIVING
