1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Phenom II / Athlon II
processors (Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 2.0
FSB
Support Hyper Transport 3.0
Supports up to 3.2 GT/s Bandwidth
Chipset
AMD 760G
AMD SB710
Super I/O
ITE 8728
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Mon itor
ITE's "Smart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/1GB/
2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800/1066/1333/1600(OC)
Registered DIMM and ECC DIMM is not supported
Graphics
Integrated in AMD 760G Chipset Max Shared Video Memory is 512MB
SATA II
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Vers ion 2.0 specific at ion co mp liant
LAN
Realtek RTL 8105T 10 / 100 Mb/s auto negotiation
Sound
VT1708B
5.1 channels audio out
High Definition Audio
PCI Express X16 slot x1 Supports PCI-E X16 expansion card
Slots
PCI slot x1 Supports PCI expansion cards
SATA Connector x4 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
On Board
Connectors
