Biostar M7VIQ User Manual

M
M
M
o
o
o
t
t
t
h
h
h
e
e
e
r
r
r
b
b
b
o
o
o
a
a
a
r
r
r
d
d
d
D
D
D
e
e
e
s
s
s
c
c
c
r
r
r
i
i
i
p
p
p
t
t
t
i
i
i
o
o
o
n
n
n
6
Power Connectors: JATXPWR1
DIMM Power Selection Connector: JDIMMVOLT
 It strongly recommended to set DDR DIMM voltage in default setting
2.5V, and it for over voltage function.
Wake On LAN Header: WOL1
Clear CMOS Jumper:
JCMOS
WOL1
1
5V_SB Wake up
Ground
JATXPWR1
(ATX Main Power Conn.)
JATXPWR1
(ATX Main Power Conn.)
1
2
JDIMMVOLT
Pin 1-2 on ==> 2.5V
Pin 3-4 on ==> 2.6V
Pin 5-6 on ==> 2.7V
Pin 7-8 on ==> 2.8V
(Default ==> 2.5V)
JCMOS1
Clear CMOS
Data
Pin 1-2 on
Normal
Operation
(default)
Assignment
1
Pin 2-3 on
1

Biostar M7VIQ Specifications

General

Form Factor	Micro ATX
Maximum Memory	2 GB
USB Ports	4 x USB 2.0
Expansion Slots	1 x AGP, 3 x PCI
Onboard LAN	VIA VT6103 10/100Mbps Fast Ethernet
Storage	2 x IDE
Audio	AC'97 Audio
LAN	VIA VT6103 10/100Mbps Fast Ethernet
