NF520-A2 TE/NF520-A2 SE/NF520-A2
16
4 Advanced Chipset Features
This submenu allows you to configure the specific features of the chipset
installed on your system. This chipset manage bus speeds and access to system
memory resources, such as DRAM. It also coordinates communications with the
PCI bus. The default settings that came with your system have been optimized
and therefore s ho uld not be c hanged unless yo u are susp icious that the settings
have been changed incorrectly.
Figure 4: Advanced Chipset Setup
K8<->NB HT Width
This item allows you to select the K8<->NB HT Width.
The Choices: Auto(def ault ), [↓16 ↑16],[↓8 ↑8].
PCIE/SATA Spread Spectrum
This item allows you to enable/disable the Spread Spectrum function.
The Choices: Disabled (default), Triangular Down.
To Next Page
