SYMBOLS
The label on your tool may include the
following symbols. The symbols and their
definitions are as follows:
V .........................volts
A ........................amperes
Hz ......................hertz
W .......................watts
min ...................minutes
or AC .........alternating current
or DC ...... direct current
n
o ...................... no load speed
......................Class I Construction
(grounded)
.......................earthing terminal
.....................safety alert symbol
...............Class II Construction
(double insulated)
.../min or rpm...revolutions or
reciprocation per minute
............... Read instruction manual
before use
..................... Use proper respiratory
protection
..................... Use proper eye protection
..................... Use proper hearing protection
4
FUNCTIONAL DESCRIPTION
1) Trigger switch
2) Forward/Reverse/Lock-off slider
3) Roto bit holder
4) Magnetic screw holder
5) Hex spindle
6) LED light
7) Charger port
8) Charger
9) Charger jack
A
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
• Avoid prolonged contact with dust
from power sanding, sawing, grinding,
drilling, and other construction
activities. Wear protective clothing
and wash exposed areas with soap
and water. Allowing dust to get into
your mouth, eyes, or lay on the skin may
promote absorption of harmful chemicals.
WARNING: Use of this tool can
generate and/or disperse dust, which
may cause serious and permanent
respiratory or other injury. Always use
NIOSH/OSHA approved respiratory
protection appropriate for the dust
exposure. Direct particles
away from face and body.
8
7
5
6
4
3
2
1
9
