9
ENGLISH
(Original instructions)
Assembly
Fitting and removing a screwdriver bit or
socket (fig. A)
Warning! Make certain the tool is locked to
prevent switch actuation before installing or
removing accessories.
• To fit a screwdriver bit (9), push it into
the bit holder (3) until it locates.
• To remove a screwdriver bit, pull it
straight from the bit holder.
Use
Warning! Let the tool work at its own pace.
Do not overload.
Charging the battery (fig. B)
The battery needs to be charged before first
use and whenever it fails to produce
sucient power on jobs that were easily
done before. The battery may become
warm while charging; this is normal and
does not indicate a problem.
Warning! Only use the charger provided to
charge CS3653LC.
• To charge the battery, insert the charger
plug (10) into the connector (6).
• Plug in the charger.
• The state of charge indicator (fig. B) will
display the current level of charge in the
tool.
• Leave the tool connected to the charger
for 3 hours.
The charger may hum and become warm
while charging; this is normal and does not
indicate a problem.
Warning! Do not charge the battery at
ambient temperatures below 10 °C or above
40 °C. Recommended charging
temperature: approx. 24 °C.
State of charge indicator (fig. B)
The tool is fitted with a state of charge
indicator. This can be used to display the
current level of charge in the battery during
use and during charging.
During charging
• During charging the state of charge
indicator will automaticaly show the
current level of charge.
During use
Note: Do not check state of charge while
screwdriver is in use or under load. This will
result in an inacurate reading. To receive an
accurate reading, check the state of charge
with the tool under no load.
• Set the tool to the forward position. The
state of charge indicator will not function
with the tool set in reverse or in the lock
o position.
• Press the trigger switch (1). The LED's in
the state of charge indicator (8) will light
up depending on the level of charge
remaining.
Adjusting the handle (fig. C & D)
For optimum versatility, the handle can be
set to two dierent positions.
• Press the handle adjustment button (4).
• Twist the handle into the desired position.
• Release the button.
Number of LED's
Three
Two
One
Zero
Charge level
Battery full
Battery OK
Battery low
Battery Empty, charge immediately.

Black & Decker CS3653LC Specifications

General

Power source	Battery
Charging time	2.5 h
Battery voltage	3.6 V
Battery capacity	1.5 Ah
Battery level indicator	Yes
Product color	Black, Orange
Number of gears	1
Idle speed (max)	190 RPM
Screw diameter (max)	- mm
Maximum torque (hard applications)	6 N⋅m
Quantity per pack	1 pc(s)
