Motor
Be sure your power supply agrees with nameplate marking. 120 Volts AC only means your
tool will operate on standard 60 Hz household power. Do not operate AC tools on DC. A
rating of 120 volts AC/DC means that you tool will operate on standard 60 Hz AC or DC
power. This information is printed on the nameplate. Lower voltage will cause loss of power
and can result in over-heating. All Black & Decker tools are factory-tested; if this tool does
not operate, check the power supply.
Operating Instructions
WARNING: To reduce the risk of serious personal injury, read and follow all important
safety warnings and instructions prior to using this tool.
Switch
To turn the tool ON, hold it as shown in Figure 1 and push the portion of the switch marked
"I". To turn the tool OFF, push the portion of the switch marked "O".
Operation (Figure 1)
Grasp product as shown in figure 1 and turn it on. NOTE: Do not rest fingers on platen
during use. Move it in long sweeping strokes across the surface, letting it do the work. Light
pressure is all that is required for sanding, polishing or scrubbing. Excessive pressure will
slow the tool and produce inferior results. Check your work often, product is capable of
removing material rapidly.
WARNING: Shock hazard. Under no circumstances should this product be used near water.
CAUTION: To reduce the risk of injury, turn off and unplug the tool before making any
adjustments or removing or installing attachments or accessories.
Detail Sanding
Your tool is equipped with a teardrop base which allows you to use it on large flat surfaces
and tight spots or corners.
The pad tips may wear unevenly, depending on use. The pads are designed to allow you to
interchange and /or rotate the diamond tip.
Fitting sanding sheets (Fig. 2)
• Detach the two diamond-shaped tips from the sanding sheet.
• Hold the tool with the sanding base facing upwards.
• Place the sanding sheet onto the sanding base.
The diamond-shaped tip can be reversed and replaced when worn.
• When the front part of the tip is worn, detach it from the sheet, reverse it and press it onto
the sanding base again.
• When the whole tip is worn, remove it from the sanding base and fit a new tip.
Tip of the Sanding Base (Fig. 3)
When the sanding base tip is worn, it can be reversed or replaced.
• Reverse or replace the worn part.
Finger Attachment (Fig. 4)
The finger attachment is used for fine detail sanding.
• Remove the screw.
• Remove the diamond-shaped tip holder from the sanding base.
• Fit the finger attachment onto the sanding base.
• Fit and tighten the screw.
• Align the sanding sheet with the finger attachment.
Contour Holder Attachment (Fig. 5)
• The contour sanding pieces are for sanding curved surfaces and grooves.
• Remove the screw.
• Remove the diamond-shaped tip holder from the sanding base.
• Fit the contour holder onto the sanding base.
• Fit and tighten the screw.
Fitting and Removing a Contour Piece (Fig. 6 & 7)
• Choose the contour sanding piece profile most suitable for your application.
• Place one end of the contour sanding piece into the recess at the front end of the contour
holder.
7
