Blaupunkt Monte Carlo MP34 User Manual

EA
6.
AB
1 nc 1 Speaker out RR+
2 Radio/Tel. mute 2 Speaker out RR-
3 nc 3 Speaker out RF+
4 Permanent +12V 4 Speaker out RF-
5 Aut. antenna 5 Speaker out LF+
6 nc 6 Speaker out LF-
7 Kl.15/Ignition 7 Speaker out LR+
8 Ground 8 Speaker out LR-
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C
B
A
14
7
10 13
16
19
3
6
9
12
15
18
2
58
11
14 17
20
C-1 C-2 C-3
C
C1 C2 C3
1 Line Out LR 7 nc 13 CDC-Data - In
2 Line Out RR 8 nc 14 CDC-Data - Out
3 Line Out / Ground 9 nc 15 Permanent +12V
4 Line Out LF 10 RC +12V 16 +12V
5 Line Out RF 11 Remote Control 17 Bus / GND
6 +12V Amplifier 12 RC - GND 18 AF / GND
19 Line In - L
20 Line In - R
Equalizer Amplifier
 
 ! 
CD-Changer
CD-
CD-
Remote Control

 !"
BahamasMP34 28/11/2003, 3:31 PM80
