BLUM SERVO-DRIVE User Manual

1
2
3a 3b
4
5
6
7
1
2
10
SERVO-D RIVE
Instruction leaet
Lift mechanism, drive unit and cover
cap
Lever arm
SERVO-DRIVE power supply unit
SERVO-DRIVE plug-in power supply unit
SERVO-DRIVE switch
Blum distance bumper
Cabinet
Front/Lift system
Reference diagram
SERVO-DRIVE for AVENTOS supports the opening and closing of lift systems in furniture.
SERVO-DRIVE for AVENTOS/SERVO-DRIVE uno for AVENTOS
1
2
3a
3b
4
5
6
7
Press on the front
➢ The lift system opens automatically
Press on the SERVO-DRIVE switch
➢ The lift system closes automatically
The SERVO-DRIVE switch triggers the automatic opening and closing action of SERVO-DRIVE
for AVENTOS.
Electrical motion support system

BLUM SERVO-DRIVE Specifications

General

Brand	BLUM
Model	SERVO-DRIVE
Category	Servo Drives
Language	English
