Accessing the turn signals and low beams
Follow the general instructions on lamps and
bulbs, refer to page 183.
1. In the wheel house, loosen the two brack‐
ets and remove the cover.
Turn signal
21-watt bulb, PY21W
1.
If necessary, pull the inside trim of the
wheel house slightly inward. Turn the bulb
holder counterclockwise and remove.
2. Press the bulb gently into the socket, turn
counterclockwise and remove.
3. Install the new bulb and the bulb holder in
reverse order of removal.
4. Attach the cover to the wheel house.
Low beams
55-watt bulb, H7.
1. Turn the cover counterclockwise and re‐
move.
2. Tilt the bulb down and then up to loosen it
from the holder and remove.
3. Pull the connector off the bulb.
4. Attach the connector to the new bulb.
5. First insert the bulb at the top with the
strap, arrow 1, and then press down firmly,
arrow 2. The bulb must audibly latch in
place.
6. Close the headlamp housing with the cap.
Make sure that the cap engages.
7. Attach the cover to the wheel house.
Seite 185
Replacing components Mobility
185
Online Edition for Part no. 01 40 2 924 974 - X/13
