BMW 5 series Installation Instructions And Specification

1. Preparations
Before installing the auxiliary heating system
conduct a short test and then disconnect the
battery.
The following parts must be removed
- Footwell trim on the A pillar on the
driver’s side
- Pedals trim
- Side trims for heater/air conditioner
- Heating/air conditioning controller
- Glove box
- Footwell trim on the A pillar on the
passenger’s side
- Internal sill skirts on the passenger’s side at
the front and rear
- Rear seat bench and rear seat backrest
- Wheel arch trim at the front left
- C pillar trim on the right
- Double water valve (cars with IHKA only)
- Microfilter casing on the left
- Trim above the brake booster
2. Installation and cabling diagram
F 39 00 28 2W
Legend
1. Auxiliary heater
2. Double water valve with additional water
pump*
3. Auxiliary heating system wiring harness
4. Remote control receiver**
5. Fuse holder
6. Adhesive aerial**
* Cars with IHKA only
** Saloon models only, on touring models the
remote control receiver is in front of the spare
wheel trough, the adhesive aerial is fitted on the
right-hand rear side window.
3. Connection diagram for the
auxiliary heating system wiring
harness
F 39 00 40 2W
18/EN
A
A1
A2
B
C
D
E
F
Additional water pump, X122
Additional water pump
connector
Additional water pump
connector
Auxiliary heater, X764
IHKA control connector
Remote control receiver,
X18830
Terminal 30 connector
Earth, X498
–––––
0.50 mm
2
0.50 mm
2
0.35 mm
2
0.50 mm
2
–––––
2.5 mm
2
0.75 mm
2
–––––
blue/green
brown
white/green
blue/green
–––––
red/yellow
brown
On the additional water pump M37*
On the additional water pump M37, black 2-pin
plug, slot No. 1*
On the additional water pump M37, black 2-pin
plug, slot No. 2*
On the auxiliary heater A14, X764, black 6-pin plug,
slot No. 1
On IHKA control A11, X610, 26-pin blue plug,
slot No. 9
In the area below the C pillar on the right-hand side
on the remote control receiver A128
Fuse holder II at the rear right-hand side of the
boot, fuse F47
At the rear right-hand side of the boot below the
light unit on ground post X498
Item Description Cable colour
Cross-
section
Installation location in the car
* Cars with IHKA only
