All around the center console
1 Headliner 18
2 Control Display 19
3 Glove compartment, top/bottom 138
4 Air vent 128
5 Hazard warning system 266
Central locking system 39
6 Radio 172
CD/Multimedia 179
7 Automatic climate control 125
8 Controller with buttons 19
9 Parking brake 66
Auto Hold 68
10 PDC Park Distance Con‐
trol* 113
Top View* 119
Backup camera* 116
Side View* 118
HDC Hill Descent Control* 99
11 Dynamic Driving Control 102
DSC Dynamic Stability Con‐
trol 102
12 Transmission selector lever
Seite 17
17
Online Edition for Part no. 01 40 2 606 497 - 03 11 490
