23
E60 Complete Vehicle
Doors and Exterior Door Handles
The doors are composed of a door
outer panel, a door inner panel, a
door outer skin reinforcing bar, a
lock plate and a diagonally mount-
ed side-impact bar.
1. Diagonally mounted side-impact bar
2. Exterior door handle mounting plate
with door handle and recess plate
3. Lock
The door control module is inte-
grated in the door. The door lock
is an L-type lock that has been
used on the basic version of the
E65 since 09/02.
The exterior door handle is a three-piece assembly. It consists of a mounting plate fitted
from the inside, a handle recess plate fitted from the outside and the handle fitted and
screwed onto the recess plate from the outside (access screw from outside - arrow, above).
Workshop Exercise - Exterior Door Handle Removal
The Instructor will demonstrate the proper door handle release and attachment procedure
using mockup parts and special tool. This will familiarize you before attempting “on vehi-
cle” removal. After the demonstration is completed, proceed to “on vehicle” removal and
installation.
CCaauuttiioonn:: LLiifftt hhaannddllee uunnttiill aacccceessss hhoollee ((ttoo ssccrreeww)) iiss eexxppoosseedd aanndd iinnsseerrtt ttooooll ttoo eennggaaggee iinn
ssccrreeww,, ddoo nnoott oovveerrttiigghhtteenn sseeccuurriinngg ssccrreeww iinn eeiitthheerr ddiirreeccttiioonn!!
11.. TToo rreemmoovvee ddoooorr hhaannddllee,, ttuurrnn ssccrreeww ccoouunntteerr
cclloocckkwwiissee aaggaaiinnsstt ssttoopp.. PPuullll rreeaarr ooff hhaannddllee
oouutt,, ppiivvoott aanndd ppuullll hhaannddllee ooffff ooff ffrroonntt ppiinn..
22.. TToo iinnssttaallll hhaannddllee,, ppoossiittiioonn oonn ffrroonntt ppiinn aanndd
sswwiivveell iinnttoo ppllaaccee.. PPuusshh rreeaarr ooff hhaannddllee iinnttoo
ssoocckkeett ((lliigghhttllyy)) uunnttiill iitt ssnnaappss iinn ((sslliigghhtt rreessiiss--
ttaannccee)).. TTuurrnn ssccrreeww cclloocckkwwiissee uunnttiill iitt sseeaattss..
RReemmoovvee ttooooll,, rreelleeaassee ddoooorr hhaannddllee..
KT-10954
512220
