G07�Complete�Vehicle
4.�General�Vehicle�Electronics
31
Index Explanation
46 Tailgate�function�module�(HKFM)
47 Power�Control�Unit�(PCU)
48 Rear�radar�sensor�short�range�right�(HRSNR)
49 Vertical�Dynamic�Platform�(VDP)
50 Rear�view�camera�(RFK)
4.2.1.�Telematic�Communication�Box�(TCB)
The�G07�is�fitted�with�the�TCB�3.�Compared�with�the�TCB�2,�the�casing�dimensions�have�been
reduced.�The�unit�is�a�modular�design.�The�configuration�can�be�adapted�to�suit�the�basic�or�optional
equipment,�which�simultaneously�reduces�the�number�of�variants.�Equipment�retrofits�are�also
possible.
4.2.2.�Top�Rear�Side�View�Camera�(TRSVC)
The�TRSVC�control�unit�on�the�G07�is�located�in�the�luggage�compartment�behind�the�right-hand
side�trim�panel.�On�the�G05,�the�control�unit�was�fitted�at�the�front�on�the�left�in�the�instrument�panel
support.
4.3.�Headlight
4.3.1.�Overview
The�following�exterior�light�versions�are�offered�for�the�G07:
• Adaptive�Full�LED�Lights�(standard)
• Icon�Adaptive�LED�Headlights�with�Laserlight�(Option�SA5AZ).
Like�the�G05,�the�G07�no�longer�features�the�customary�rotary�light�switch.�The�new�light�switch�panel
only�has�buttons.
The�low-beam�headlight�is�automatically�switched�on�when�the�system�recognizes�that�it�is�dark,�even
in�the�OFF�mode�and�when�driving�readiness�is�activated�(country-specific).
