Instrument cluster
1 Fuel gauge with indicator lamp
for fuel reserve 70
2 Indicator lamp for turn signals 22
3 Speedometer
4 Indicator lamp for high beams 22
5 Tachometer and
engine oil temperature gauge 70
6 Engine coolant temperature
gauge 71
7 Indicator and warning lamps
(clockwise) for:
>
Parking brake 21
>
Brake hydraulic system, Dynamic
Brake Control (DBC)
*
20, 21
>
Antilock Brake System (ABS) 21
>
Airbags 21
>
Please fasten safety belts 21
>
Cruise control
*
22
8 CHECK button 72
9 Outside temperature display 69
10 Indicator lamp for Dynamic
Stability Control (DSC) 21
11 Trip odometer 69
12 Check Control display 72
13 Odometer 69
14 Service Interval Display 71
15 Trip odometer, reset to zero 69
16 Indicator and warning lamps
(clockwise) for:
>
Fog lamps 22
>
Battery charge current 20
>
Engine oil pressure 20
>
Service Engine Soon 21
You can display the outside
temperature and distance driven
in different units of measurement.
<
