Visor
Removing visor
Prerequisite: Chin part is closed
and visor is fully open.
Press release buttons 1 on
both sides and pull visor 2 for-
ward out of guide arrow.
Installing visor
Insert visor 1 on both sides in
guide arrow of the visor sup-
ports and push backward.
The visor engages with an aud-
ible click.
Inner visor pane
Removing the inner visor
pane
If light passes through a
medium of a different dens-
ity, approx. 4 % of light is re-
flected every time. This effect
occurs on the outer pane as well
as on the inner pane. The result
are increased projections by re-
flection. This can cause irritation
when riding by night or in the
rain. If this should be perceived
as disturbing, it is advised not to
use the inner pane. In this case,
the excenter pins in the visor
must be replaced with dummy
plugs.
Slightly over-tension visor 1.
Lift inner visor pane 2 on
one side and pull it from the
pins arrows.
Remove the other side the
same way.
4
8
z
Maintenance
