128n
Cargo area
6. Pull down the partition net downward
on both sides by the loop, refer to
arrow, and hook the hook into the
eye on the backrest
The case with the roll-up cover is
not shown in the illustration. With
the case removed it is easier to hook
the hooks of the partition net onto the
backrest.<
530de351
7. When the rear backrests are folded
down, you can unhook the partition
net from the retaining straps, com-
pletely unroll it, insert it in the front
retainers on the roof and attach the
three hooks into the eyes on the
backrests.
The illustration shows securing at the
bottom right as an example.
530de352
Side covers
Pull the handle to open the side covers.
530de290
