Bogen UDMS800HH User Manual

2
SYSTEM FEATURES
UDR800 RECEIVER
• Unsurpassed state-of-the-art PLL UHF performance with 120 dB dynamic range and operation,
up to 500 ft. (line-of-sight)
• 800 user-selectable UHF frequencies, one touch Auto-Scan/Sync open channel automatic
selection and sync
• ASC™ (Auto-Sync Channels) download feature sends selected Channel information to
transmitter via IR sender for easy frequency synchronization
• Sophisticated IF filtering for optimal simultaneous operation of multiple systems in same location
• DigiTRU Diversity™ for maximum range and dropout protection
• 120dB Dynamic Range — the quietest and best sounding UHF wireless available at any price
• Tone Squelch™ for locking out potential interference, and special circuitry for noiseless
transmitter ON/OFF switching
• Dual front panel permanently attached swivel antennas
• Front panel with LCD displays A/B diversity, Group/Channel with frequency, ASC™ transfer
status, RF/AF level, Mute (squelch) level, and push On/Off power switch
• Back panel with fixed Balanced XLR, MIC Level and adjustable unbalanced ¼” jacks, audio
Line outputs and DC input jack
• Half-rack receiver design with top folding dual antennas
• Unique snap-out side panel locking tabs for single receiver or dual receivers (side-by-side)
optional rack mounting (mounting kits sold separately)
• Externally powered with included DC adapter (22V DC 400 mA)
• Choice of transmitters: UHT800 Handheld MIC or UBP800 Body-Pack
UHT800 HANDHELD MIC TRANSMITTER
• Sleek metal housing with internal antenna for optimum aesthetics and durable long life
• Unidirectional neodymium dynamic cartridge for optimum true sound, maximum feedback
rejection and minimal handling noise
• 800 easily selectable channels via IR Sync for easy synchronization with receiver selected
channel
• Easy accessible audio level adjustment for optimum sound
• Power On/Off and Audio mute switch allows convenient audio muting with the transmitter “ON”
• Status LED indicators for unit “ON” (Green) and for low battery alert “ON” (Red)
• Convenient, economical operation with two AA alkaline or NiMH batteries
UBP800 BODY-PACK TRANSMITTER
• 800 easily selectable channels via IR Sync for easy synchronization with receiver selected
channel
• Easy accessible input level adjustment for optimum sound
• Power On/Off and Audio mute switch allows convenient audio muting with the transmitter “ON”
• Bi-color LED status indicator for unit “ON” (Green) and for low battery alert “ON” (Red)
• Convenient, economical operation with two AAA Alkaline or NiMH batteries
• Ultra compact housing, removable antenna and unique locking 3.5mm mini plug connector
for the microphone cable
WirelessManualNEW11.10_Layout 1 11/18/11 2:01 PM Page 4

Bogen UDMS800HH Specifications

General

Type	Wireless Microphone System
Transmitter Type	Handheld
Modulation	FM
Audio Frequency Response	50 Hz - 15 kHz
Dynamic Range	>90 dB
Battery Life	Up to 8 hours
Microphone Type	Dynamic
Polar Pattern	Cardioid
Impedance	600 Ohms
Connector	XLR
Color	Black
Diameter	50mm
Power Supply	2x AA Batteries
