-6-
Model number 11222EVS
Shank style SDS Max
Maximum Capacities:
Carbide tipped bits 1 1/8"
Thin wall core bits 3 1/8"
NOTE: For tool specifications refer to the nameplate on your tool.
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Rotary Hammer
DUST
SHIELD
LOCKING
SLEEVE
AUXILIARY
HANDLE
HAND GRIP
SELECTOR DIAL
RELEASE BUTTON
DEPTH
GAUGE
FIG. 1
WING KNOB
SERVICE
REMINDER
LIGHT
VARIABLE
SPEED DIAL
TRIGGER
SWITCH
VENTILATION
OPENINGS
