Bosch 11255VSR User Manual

-6-
Functional Description and Specifications
Disconnect the plug from the power source before making any assembly,
adjustments or changing accessories.
Such preventive safety measures
reduce the risk of starting the tool accidentally.
!
WARNING
Rotary Hammer
Model number 11253VSR 11255VSR
Shank style
SDS-plus
®
SDS-plus
®
Maximum Capacities:
Carbide tipped bits 1" 1"
Thin wall core bits 2-5/8" 2-5/8"
NOTE: For tool specifications refer to the nameplate on your tool.
DUST
SHIELD
VENTILATION
O
PENINGS
REVERSING
SWITCH
LEVER
VARIABLE SPEED
TRIGGER SWITCH
LOCKING
SLEEVE
DEPTH GAUGE
RELEASE BUTTON
RELEASE BUTTON
SELECTOR DIAL
HAND GRIP
AUXILIARY HANDLE
DUST
SHIELD
VENTILATION
OPENINGS
REVERSING
SWITCH
LEVER
VARIABLE SPEED
TRIGGER SWITCH
DEPTH
GAUGE
LOCKING
SLEEVE
DEPTH GAUGE
RELEASE BUTTON
RELEASE BUTTON
SELECTOR DIAL
SELECTOR DIAL
HAND GRIP
AUXILIARY HANDLE
FIG. 1
SELECTOR DIAL
DEPTH
GAUGE
HAMMERHOOK
™
(Model 11255VSR only)
