English – 2
Technical Data
Battery Charger Standard Charger
(36–4/230)
Compact Charger
(36–2/100-230)
Product code BCS220 BCS230
Rated voltage V~ 207to264 90to264
Frequency Hz 47to63 47to63
Battery charging voltage V= 36 36
Charging current (max.) A 4 2
Charging time
– PowerPack 300, approx. h 2.5 5
– PowerPack 400, approx. h 3.5 6.5
– PowerPack 500, approx. h 4.5 7.5
Operating temperature °C 0to+40 0to+40
Storage temperature °C +10to+40 +10to+40
Weight, approx. kg 0.8 0.6
Protection rating IP40 IP40
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
Power cable Australia
Article number 1 270 020 344
Rated voltage – cable V~ 300
Rated voltage – connector/plug
connector
V~ 250
Rated current – connector/plug
connector
A 10/2.5
Material – cable PVC
Safety standard – cable AS/NZS 3191
Safety standard – connector/plug
connector
AS/NZS 3112
AS/NZS 3109
Length, approx. m 1.5
Operation
Start-up
Connecting the charger to the mains (see figure A)
u Pay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the charger. Chargers marked 230 V can
also be operated at 220 V.
Plug the device connector (3) of the power cable into the
device socket (2) on the charger.
Connect the power cable (country-specific) to the mains.
Charging the Removed eBike Battery (see figureB)
Switch the eBike battery off and remove it from its holder on
the eBike. When doing so, read and observe the operating
instructions of the eBike battery.
u Ensure the eBike battery is placed on clean surfaces
only. Avoid getting dirt, e.g. sand or soil, in the charging
socket and contacts in particular.
Plug the charging connector(5) of the charger into the char-
ging socket(6) on the eBike battery.
Charging the eBike battery on the eBike (see figuresC
andD)
Switch the eBike battery off. Clean the cover of the charging
socket(7). Avoid getting dirt, e.g. sand or soil, in the char-
ging socket and contacts in particular. Lift the cover of the
charging socket(7) and plug the charging connector(5) into
the charging socket(6).
u There is a risk of fire due to the charger heating up
during charging. Ensure the eBike battery on the
eBike is completely dry and placed on a fireproof sur-
face before charging. If this is not possible, remove the
eBike battery from the holder and charge it in a more suit-
able location. When doing so, read and observe the oper-
ating instructions of the eBike battery.
Charging Process for Two eBike Batteries
If two eBike batteries are fitted to an eBike, both eBike bat-
teries can be charged using the uncovered connection. To
begin with, both eBike batteries are charged one after the
other until they reach approx.80–90% capacity, then they
are both fully charged at the same time (the LEDs flash on
both eBike batteries).
When the eBike is in operation, power is drawn from both
eBike batteries on an alternating basis.
If you take the eBike batteries out of the holders, you can
charge each one individually.
Charging process
The charging process begins as soon as the charger is con-
nected to the eBike battery or charging socket on the eBike
and to the mains.
Note: The charging process is only possible when the tem-
perature of the eBike battery is within the permitted char-
ging temperature range.
0 275 007 XCX | (04.04.2023) Bosch eBike Systems
