English–1
1 609 929 E39 • (06.02) T
1) at 25 °C
2) along the axis
Please refer to the article number on the nameplate of your unit since the
trade designation of individual units can vary.
The serial number 15 of your unit for positive identification is located on
the nameplate on the rear of the housing.
Measured values determined according to EN 60745.
Typically, the A-weighted sound pressure level of the product is less than
70 dB(A).
The unit is intended for projecting and checking precise horizontal planes,
vertical lines, alignment lines and plumb points.
Product Specifications
Construction Laser BL 40 VHR
PROFESSIONAL
Article number 0 601 096 703
Laser type 635 nm, <1 mW
Laser class 2
Working range
1)
Without receiver
With receiver
To approx. 50 m
To approx. 100 m
Levelling accuracy
1) 2)
<±0.3 mm/m
Rotational speed 3 Steps (70–680 RPM)
Laser beam diameter
at the unit
1)
Approx. 5 mm
Batteries 2 x 1.5 V LR20 (D)
Operating time approx. 40 h
Tripod connection 1/4" horizontal and vertical
5/8" horizontal and vertical with adapter
Dimensions 150 mm x 120 mm x 140 mm
Weight in accordance with
EPTA-Procedure 01/2003 1 kg
Protection type IP 54
(dust and splash water protected)
Operating temperature –5 ... +45 °C
Storage temperature –20 ... +70 °C
Noise Information
Intended Use
bl40_bu1_1609929E39_t.fm Seite 1 Dienstag, 14. Februar 2006 3:14 15
