Appliance details
7
2.3 Specification tables
Model HP200-1E...
Running models Economy Auto E-heater
Running ambient temp. °F 45 - 115 45 - 115 -5 - 130
Outwater Temp. °F Default 120°,100°F - 140°F
Power supply Ph/V/Hz 1-240-60
Storage size US Gal 50
Water heating
Capacity kW / BTU/h 1.50 / 5123 1.50 / 5123 4.00 / 13661
Max. input kW / BTU/h 0.80 / 2732 4.50 / 15368 4.00 / 13661
First Hour Rating US Gal - 56.00 52.00
Max. current A 6.5 21.6 18.7
Ambient temp. °F - 5 - 130
Unit
Dimension (D×H) inch Ø22.4 × 64.5
Packing (W×H×D) inch 25 × 68.5 × 27
Weight lbs 209.4 / 242.5
Noise level dB(A) 48
Refrigerant type/quantity lbs R134a/1.7
Refrigerant design pressure PSIA 331/86 at ambient 70°F
Tank design pressure PSI 150
Throttling type Thermal expansion valve
System protection TCO, TDO, P&T valve, over-load protector temp.
ground fault protector etc.
Air flow Ft
3
/h 13066 / 9888 / 7063
Compressor
Model FFC110HBX
Type Piston
Brand Embraco
Input kW 0.7
Fan motor
Model YDK12-6B
Brand welling
Input W 40
Speed RPM 970/750/550
Water pipeline
Water inlet pipe Male NPT ¾
Water outlet pipe Male NPT ¾
Drainage pipe Hose fitting NPT ¾
PT valve joint Female NPT ¾
Max. pressure psi 145
Heat exchanger Dividing wall type heat exchanger
E-heater kW 4.0 × 2
Table 1
