English | 17
Bosch Power Tools 1 609 92A 10F | (15.1.15)
Declaration of Conformity
We declare under our sole responsibility that the product described un-
der “Technical Data” complies with all applicable provisions of the direc-
tive 2006/42/EC including its amendments.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY
Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 16.12.2014
Assembly
Before any work on the screwdriver with drilling adapter (e.g.
maintenance etc.) as well as during transport and storage, set the
rotational direction switch to the middle position. There is danger
of injury when unintentionally actuating the On/Off switch.
Mounting the drilling adapter (see figures A1 – A2)
– Before mounting the drilling adapter 1, you have to pull the rubber cap
7 of the screwdriver off toward the front.
– Then attach the drilling adapter 1 to the screwdriver.
You can mount the drilling adapter with the padlock symbol on the re-
lease ring 4 pointing upward or offset by 45°.
The drilling adapter must audibly engage.
Dismounting (see figures B1–B2)
– Turn the release ring 4 in rotation direction and pull the drilling
adapter off toward the front ().
– Afterwards, mount the rubber cap 7 onto the screwdriver again.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
OBJ_BUCH-2328-002.book Page 17 Thursday, January 15, 2015 3:25 PM
