English | 9
Bosch Power Tools 1 609 92A 297 | (21.4.16)
4 Latch of battery lid
5 Serial number
6 Laser warning label
7 Reception lens
8 Laser beam outlet
9 Laser target plate*
10 Laser viewing glasses*
11 Protective pouch*
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a Auto-sum
b Previous measuring value
c Current measuring value
d Laser, switched on
e Length measurement
f Battery low indicator
g Temperature warning
h Error message “Error”
Assembly
Inserting/Replacing the Batteries
Using alkali-manganese or rechargeable batteries is recommended for operation of
the measuring tool.
With 1.2-V-rechargeable batteries fewer measurements could be possible than with
1.5-V-batteries.
To open the battery lid 3, press the latch 4 and remove the battery lid. Insert the bat-
teries/rechargeable batteries. When inserting, pay attention to the correct polarity
according to the representation on the inside of the battery compartment.
When the battery symbol appears for the first time on the display, at least 100 in-
dividual measurements are still possible.
When the battery symbol flashes, the batteries/rechargeable batteries must be re-
placed. Measurements are no longer possible.
Always replace all batteries/rechargeable batteries at the same time. Do not use dif-
ferent brands or types of batteries/rechargeable batteries together.
OBJ_BUCH-2099-004.book Page 9 Thursday, April 21, 2016 1:10 PM
