Safety Notes
All instructions must be read and observed
in order to work safely with the measuring
tool. Never make warning signs on the
measuring tool unrecognisable. SAVE
THESE INSTRUCTIONS FOR FUTURE REF-
ERENCE AND INCLUDE THEM WITH THE
MEASURING TOOL WHEN GIVING IT TO A
THIRD PARTY.
Caution – The use of other operating or adjusting
equipment or the application of other processing meth-
ods than those mentioned here can lead to dangerous
radiation exposure.
The measuring tool is provided with a warning label
(marked with number 10 in the representation of the
measuring tool on the graphics page).
If the text of the warning label is not in your national
language, stick the provided warning label in your na-
tional language over it before operating for the first
time.
Do not direct the laser beam at persons
or animals and do not stare into the di-
rect or reflected laser beam yourself, not
even from a distance. You could blind
somebody, cause accidents or damage
your eyes.
If laser radiation strikes your eye, you must deliberate-
ly close your eyes and immediately turn your head
away from the beam.
Do not use the laser viewing glasses as safety goggles.
The laser viewing glasses are used for improved visualisa-
tion of the laser beam, but they do not protect against laser
radiation.
Do not use the laser viewing glasses as sun glasses or in
traffic. The laser viewing glasses do not afford complete
UV protection and reduce colour perception.
Do not make any modifications to the laser equipment.
Have the measuring tool repaired only through quali-
fied specialists using original spare parts. This ensures
that the safety of the measuring tool is maintained.
Do not allow children to use the laser measuring tool
without supervision. They could unintentionally blind
other persons or themselves.
Do not operate the measuring tool in explosive environ-
ments, such as in the presence of flammable liquids,
gases or dusts. Sparks can be created in the measuring
tool which may ignite the dust or fumes.
Keep the measuring tool and the laser tar-
get plate 14 away from cardiac pacemak-
ers. The magnets of the measuring tool and la-
ser target plate generate a field that can impair
the function of cardiac pacemakers.
Keep the measuring tool and the laser target plate 14
away from magnetic data medium and magnetically-
sensitive equipment. The effect of the magnets of the
measuring tool and laser target plate can lead to irreversi-
ble data loss.
Product Description and Specifica-
tions
Please unfold the fold-out page with the representation of the
measuring tool and leave it unfolded while reading the operat-
ing instructions.
Intended Use
The measuring tool is intended for determining and checking
horizontal and vertical lines as well as plumb points.
Noise Information
The A-weighted sound pressure level of the audio signal at
one meter distance is 80 dB(A).
Do not hold the measuring tool close to your ear!
Technical Data
Point Laser GPL 5 C Professional
Article number
3 601 K66 3..
Working range
1)
– Horizontal point beams
– Laser-line cross-point, upward
– Laser-lines, upward
– Laser-line cross-point, downward
– Laser-lines, downward
30 m
10 m
7m
5m
3m
Levelling Accuracy
±0.2 mm/m
1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation).
The measuring tool can be clearly identified with the serial number 11 on the type plate.
