Bosch GSB 16 RE User Manual

English | 13
Bosch Power Tools 1 609 92A 0NE | (3.6.14)
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Keyless chuck
2 “Drilling/Impact Drilling” selector switch
3 Rotational direction switch
4 Lock-on button for On/Off switch
5 On/Off switch
6 Thumbwheel for speed preselection
7 Auxiliary handle (insulated gripping surface)*
8 Depth stop*
9 Chuck key*
10 Key type drill chuck*
11 Screwdriver bit*
12 Universal bit holder*
13 Hex Key**
14 Handle (insulated gripping surface)
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
**Commercially available (not included in the delivery scope)
Technical Data
Impact Drill GSB 16 RE GSB 16 RE
Article number
3 601 A4E 5.. 3 601 A4E 6..
Rated power input
W750750
Output power
W380380
No-load speed
min
-1
0–2800 0–2800
Rated speed
min
-1
1750 1750
Impact frequency at no-load
min
-1
47600 47600
Rated torque
Nm 2.3 2.3
Speed preselection
 
Right/left rotation
 
Key type drill chuck
– 
Keyless drill chuck
 –
Fully automatic spindle locking (Auto-lock)
 –
Spindle collar dia.
mm 43 43
Max. drilling dia.
– Brickwork
–Concrete
– Steel
– Wood
mm
mm
mm
mm
18
16
13
30
18
16
13
30
Chuck clamping range
mm 1.5 – 13 1.5 – 13
Weight according to EPTA-Procedure 01/2003
kg 2.2 2.2
Protection class
/II /II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
