English | 19
Bosch Power Tools 2 609 932 659 | (4.2.09)
f Never use the machine with a damaged ca-
ble. Do not touch the damaged cable and
pull the mains plug when the cable is dam-
aged while working. Damaged cables in-
crease the risk of an electric shock.
Products sold in GB only: Your product is fitted
with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.
Products sold in AUS and NZ only: Use a resid-
ual current device (RCD) with a rated residual
current of 30 mA or less.
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
Intended Use
The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling
in wood, metal and plastic. Machines with elec-
tronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Keyless chuck
2 “Drilling/Impact Drilling” selector switch
3 Thumbwheel for electronic speed preselec-
tion (GSB 21-2 RCT)
4 “Drilling/screwdriving” selector switch
(GSB 21-2 RCT)
5 Rotational direction switch
6 Lock-on button for On/Off switch
7 Insulated handle
8 On/Off switch
9 Thumbwheel for speed preselection
10 Gear selector
11 Button for depth stop adjustment
12 Insulated auxiliary handle*
13 Depth stop*
14 Chuck key*
15 Key type drill chuck*
16 Screwdriver bit*
17 Universal bit holder*
18 Allen key **
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
**Commercially available (not included in the deliv-
ery scope)
OBJ_BUCH-909-001.book Page 19 Wednesday, February 4, 2009 7:50 AM

Bosch GSB 21-2 RCT Specifications

General

Reverse	Yes
Chuck type	Keyless
Built-in light	-
Product design	Pistol grip drill
Torque (max)	43 N⋅m
Spindle thread	1/2\
Number of gears	2
Idle speed (max)	3000 RPM
Sound power level	106 dB
Chuck capacity (max)	13 mm
Chuck capacity (min)	1.5 mm
Sound pressure level	95 dB
Idle speed (1st gear)	900 RPM
Sound level uncertainty	5 dB
Impact rate (high speed)	51000 bpm
Vibration level (screwdriving)	2.5 m/s²
Drilling diameter in wood (max)	40 mm
Drilling diameter in steel (max)	16 mm
Vibration level (metal drilling)	5.6 m/s²
Drilling diameter in concrete (max)	22 mm
Vibration level (concrete drilling)	14.6 m/s²
Vibration level uncertainty (metal drilling)	1.5 m/s²
Vibration level uncertainty (concrete drilling)	1.8 m/s²
Input power	1300 W
Output power	695 W
Power source	AC
AC input voltage	230 V

Weight and Dimensions

Depth	220 mm
Width	363 mm
Height	81 mm
Weight	2900 g
Package depth	390 mm
Package width	360 mm
Package height	110 mm
