Your tool is equipped with a variable speed
trigger switch. The tool can be turned "ON" or
"OFF" by squeezing or releasing the trigger.
The speed can be adjusted from the minimum
to maximum nameplate RPM by the pressure
you apply to the trigger. Apply more pressure
to increase the speed and release pressure to
decrease speed (Fig. 1).
#%*%%)%&"
)%'%% #
After tool use, lock trigger in
“OFF” position to help prevent
accidental starts and accidental discharge.
Your tool is equipped with a forward/
reversing lever and trigger lock located above
the trigger (Fig. 3). This lever was designed
for changing rotation of the bit, and for locking
the trigger in an “OFF” position.
For forward rotation, (with chuck pointed away
from you) move the lever to the far left (Fig. 3).
For reverse rotation move the lever to the far
right (Fig. 4). To activate trigger lock move
lever to the center off position.
<
;<A
05.;
42
16?2
0A6<;
<3
?<A.A6<; B;A69 A52 A<<9
0<:2@ A< . 0<:=92A2 @A<= Shifting during
rotation of the chuck can cause damage to
the tool.
!
CAUTION
!
WARNING
#=2?.A6;4;@A?B0A6<;@
FIG. 3
FIG. 4
-10-
@@2:/9F
6@0<;;20A /.AA2?F =.08
3?<:A<<9/23<?2 :.86;4
.;F .@@2:/9F .17B@A:2;A@<? 05.;46;4
.002@@<?62@. Such preventive safety
measures reduce the risk of starting the tool
accidentally.
"&%'"'&
Move reverse switch lever to the center “OFF”
position. Remove battery pack and rotate the
clutch ring to the drill bit symbol
“ ”. Rotate the chuck sleeve counter-
clockwise viewing from chuck end, and open
chuck to approximate drill bit diameter. Insert
a clean bit up to the drill bit flutes for small bits,
or as far as it will go for large bits. Close chuck
by rotating the chuck sleeve clockwise and
securely tighten by hand (Fig. 2).
<;<AB@2A52=<D2?<3
A52 1?699 D5692 4?.@=6;4
05B08A<9<<@2;<?A645A2;/6A Friction burn
or hand injury is possible if attempting to grasp
the spinning chuck.
!
WARNING
!
WARNING
CHUCK SLEEVE
FIG. 2
DRILL BIT
BIT HOLDER
SCREWDRIVER BIT
