Intended Use
The drive unit is intended only for driving your eBike and must
not be used for other purposes.
Product Features (see page 2–3)
The numbering of the components shown refers to the illus-
trations on the graphic pages at the beginning of the manual.
All illustrations of bike parts except for the drive unit, on-
board computer including operating unit, speed sensor and
the corresponding holders are schematic and may differ on
your eBike.
1 Joystick
2 Button “Home”
3 On-board computer
4 Holder for on-board computer
5 On/Off button for on-board computer
6 Bike lights button
7 Brightness sensor
8 USB port
9 Protective cap of USB port
10 Drive unit
11 Operating unit
12 Joystick on the operating unit
13 “Home” button on the operating unit
14 Decrease assistance level button
15 Increase assistance level button
16 Push-assistance button “WALK”
17 Lock latch for on-board computer
18 Locking screw for on-board computer
19 Speed sensor
20 Spoke magnet of the speed sensor
USB charging cable (Micro A – Micro B)*
* not illustrated; available as accessory
Technical Data
Drive Unit Drive Unit
Article number
0 275 007 030
0 275 007 032
Rated continuous output
W250
Torque at drive, max.
Nm 50
Rated voltage
V36
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Degree of protection
IP 54 (dust and splash
water protected)
Weight, approx.
kg 4
On-board computer Nyon
Article number
1 270 020 907/915
Internal memory
1 270 020 907
1 270 020 915
GB
GB
1
8
Max. charging current,
USB connection
mA 500
Charging voltage,
USB connection
V5
USB charging cable
1)
1 270 016 360
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Charging temperature
°C 0...+40
Internal lithium-ion battery
V
mAh
3.7
710
Protection type
2)
IP x7 (watertight)
Supported wi-fi standards
802.11b/g/n (2.4 GHz)
Weight, approx.
kg 0.2
1) Not included as part of standard delivery
2) When USB cover is closed
Bike lights*
Rated voltage V6
Maximum output
–Front light
–Taillight
W
W
8.4
0.6
* Not possible via the eBike battery pack in all country-specific versions,
depending on the statutory regulations
