Bosch Performance Line Original Operating Instructions

135
English – 1
Safety instructions
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Save all safety warnings and instructions for future ref-
erence.
The term eBike battery is used in these instructions to
mean all original Bosch eBike rechargeable battery packs
from the system generationthe smart system.
The terms drive and drive unit used in these operating in-
structions refer to the original Bosch drive units from the
system generationthe smart system.
u Read and observe the safety warnings and directions
contained in all the eBike system operating instruc-
tions and in the operating instructions of your eBike.
u Do not attempt to secure the on-board computer or
operating unit while riding!
u The push assistance function must only be used when
pushing the eBike. There is a risk of injury if the wheels
of the eBike are not in contact with the ground while using
the push assistance.
u When the push assistance is activated, the pedals may
turn at the same time. When the push assistance func-
tion is activated, make sure that there is enough space
between your legs and the turning pedals to avoid the risk
of injury.
u When using the walk assistance, make sure that you
can control the eBike and that you can hold it securely
at all times. Under certain circumstances, the walk as-
sistance may stop (e.g. if the pedals hit an obstacle or if
you accidentally let go of the button on the operating
unit). The eBike may suddenly move backwards onto you
or tip up. This presents a risk for the user particularly if
there is additional load on the eBike. When using the walk
assistance, do not bring the eBike into situations in which
you cannot hold the eBike using your own strength.
u Do not stand your eBike upside down on its handle-
bars and saddle if the operating unit or its holder pro-
trude from the handlebars. This may irreparably dam-
age the operating unit or the holder.
u Do not connect a charger to the eBike battery if the
display for the operating unit or on-board computer
reports a critical error. This may result in damage to
your eBike battery. The eBike battery may catch fire,
thereby resulting in serious burns and other injuries.
u The operating unit features a wireless interface. Local
operating restrictions, e.g. in aeroplanes or hospitals,
must be observed.
u Caution! When using the operating unit with Bluetooth®,
this may cause interference that affects other devices and
systems, aeroplanes and medical devices (e.g. pace-
makers, hearing aids). Likewise, injury to people and an-
imals in the immediate vicinity cannot be excluded en-
tirely. Do not use the operating unit with Bluetooth® in the
vicinity of medical devices, petrol stations, chemical
plants, areas with a potentially explosive atmosphere or
on blast sites. Do not use the operating unit with
Bluetooth® in aeroplanes. Avoid operation near your body
for extended periods.
u The Bluetooth® word mark and logos are registered trade-
marks owned by Bluetooth SIG, Inc. Any use of such
marks by Robert Bosch GmbH, Bosch eBike Systems is
under license.
u Observe all national regulations which set out the ap-
proved use of eBikes.
Privacy notice
When you connect the eBike to theBosch DiagnosticTool3
or replace eBike components, technical information about
your eBike (e.g. manufacturer, model, bike ID, configuration
data) and the eBike usage (e.g. total riding time, energy con-
sumption, temperature) is transferred to Bosch eBike Sys-
tems (Robert Bosch GmbH) for the purposes of processing
your inquiry, servicing and product improvement. You can
find further information about data processing at
www.bosch-ebike.com/privacy-full
.
Product description and
specifications
Intended use
TheLED Remoteoperating unit is designed for controlling
an eBike/on-board computer fromthe smart systemsystem
generation. You can also use it to change the assistance level
in theeBike Flow app.
So as to be able to use the operating unit fully, a compatible
smartphone with the eBike Flow app is required.
TheLED Remoteoperating unit can be connected to your
smartphone via Bluetooth®.
Depending on the smartphone's operating sys-
tem, theeBike Flow app can be downloaded
free of charge from the Apple App Store and
the Google Play store.
Use your smartphone to scan the code in order
to download theeBike Flow app.
Product features
The numbering of the components shown refers to the illus-
trations on the graphics pages at the beginning of the
manual.
All illustrations of bike parts except for the drive unit, on-
board computer (including operating unit), speed sensor
and the corresponding holders are a schematic representa-
tion and may differ on your eBike.
(1)
Ambient light sensor
(2)
On/off button
(3)
Charge indicator of the eBike battery
(4)
ABS LED (optional)
(5)
Assistance level LED
Bosch eBike Systems 0 275 007 3RL | (21.02.2023)
