16 | English
1 619 929 J64 | (22.2.12) Bosch Power Tools
10 Parallel guide
11 Retracting blade guard
12 Base plate
13 Lever for retracting blade guard
14 Wing bolt for bevel-angle preselection
15 Blade guard
16 Sawdust ejector
17 Handle (insulated gripping surface)
18 Clamping bolt with washer
19 Clamping flange
20 Saw blade*
21 Mounting flange
22 Saw spindle
23 Vacuum hose*
24 Deflection tube for chips
25 Dust/chip box*
26 Slider of dust/chip box
27 Clamping lever for cutting-depth preselection
28 Cutting-depth scale
29 Cutting mark, 45°
30 Cutting mark, 0°
31 Guide rail*
32 Button for guide-rail lock
33 Material clamp*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 92 dB(A); Sound power level
103 dB(A). Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Cutting wood: a
h
=4.0m/s
2
, K=1.5 m/s
2
,
Cutting metal: a
h
=3.0m/s
2
, K=1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Circular Saw PKS 55 PKS 55 A PKS 66 A
PKS 66 AF*
Article number 3 603 E00 0.. 3 603 E01 0.. 3 603 E02 0..
Rated power input
W12001200 1600
No-load speed
min
-1
5600 5600 5000
Cutting depth, max.
– for 0° bevel angle
– for 45° bevel angle
mm
mm
55
38
55
38
66
48
Spindle lock
z zz
CutControl
– zz
Dust/chip box
– zz
Base plate dimensions
mm 288 x 153 288 x 153 327 x 160
Saw blade diameter, max.
mm 160 160 190
Saw blade diameter, min.
mm 150 150 184
Blade thickness, max.
mm 1.8 1.8 1.8
Mounting bore
mm 20 20 30
Weight according to EPTA-Procedure 01/2003
kg 3.9 3.9 5.4
Protection class
/ II / II / II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable mains system conditions.
Malfunctions are not to be expected for system impedances below 0.36 ohm.
* PKS 66 AF with guide rail
OBJ_BUCH-841-006.book Page 16 Wednesday, February 22, 2012 3:44 PM

Bosch PKS 55 A Specifications

General

Input power	1200 W
Power source	AC
AC input voltage	240 V
Blade bore	20 mm
Blade diameter	160 mm
Idle speed (max)	5600 RPM
Sound power level	103 dB
Cutting depth (45º)	38 mm
Cutting depth (90º)	55 mm
Sound pressure level	92 dB
Sound level uncertainty	3 dB
Uncertainty K	1.5 m/s²
Position indicator	Yes
Vibration emission	2.5 m/s²

Weight and Dimensions

Weight	3900 g
