Bosch PSB 500 User Manual

English - 1
1 Keyless chuck (0 603 387 7../0 603 387 5..)
2 Spindle lock button (0 603 387 5..)
3 “Drilling/Impact Drilling” selector switch
4 Lock-on button for On/Off switch
5 On/Off switch
6 Thumbwheel for speed preselection
(0 603 387 5..)
7 Rotational direction switch
(0 603 387 6../0 603 387 7../0 603 387 5..)
8 Push-button for depth-stop adjustment
9 Winged screw for auxiliary handle adjustment
10 Auxiliary handle
(0 603 387 6../0 603 387 7../0 603 387 5..)
11 Depth stop
12 Chuck key
(0 603 387 0../0 603 387 1../0 603 387 6..)
13 Key chuck
(0 603 387 0../0 603 387 1../0 603 387 6..)
14 Screwdriver attachment (bit)*
15 Universal bit holder*
16 Allen key*
* Not all of the accessories illustrated or described are
included as standard delivery.
Measured values determined according to
EN 50 144.
Typically the A-weighted noise levels of the prod-
uct are: sound pressure level: 97 dB (A); sound
power level: 110 dB (A).
Wear hearing protection!
The typically weighted acceleration is 16 m/s
2
.
The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling in
wood, metal, ceramics and plastics. Machines
with electronic control and right/left rotation are
also suitable for screwdriving and thread-cutting.
Tool Specifications
Impact Drill PSB … 500 500-2 500 RE 500 RE 550 RE
Order number 0 603 … 387 0.. 387 1.. 387 6.. 387 7.. 387 5..
Rated power [W] 500 500 500 500 550
Output power [W] 260 260 260 260 270
No-load speed [rpm] 3 000 2 500/3 000 0–3 000 0–3 000 0–3 000
Impact rate, max. [bpm] 48 000 48 000 48 000 48 000 48 000
Torque at maximum
output power
[Nm] 7.5 7.5 7.5 7.5 7.5
Speed preselection – – – – ●
Rotational direction switch – – ● ● ●
Two-step switch – ● – – –
Key chuck ● ● ● – –
Keyless chuck – – – ● ●
Drill spindle lock button – – – – ●
Auxiliary handle – – ● ● ●
Chuck clamping range, max. [mm] 13 13 13 13 13
Maximum drilling Ø
Concrete [mm] 13 13 13 13 13
Brickwork [mm] 15 15 15 15 15
Steel [mm] 10 10 10 10 10
Wood [mm] 20 20 20 20 20
Weight (without
accessories), approx.
[kg] 1.5 1.5 1.5 1.5 1.5
Protection class / II / II / II / II / II
Please observe the order number of your machine. The trade names of the individual machines may vary.
Machine Elements Noise/Vibration Information
Intended Use
8 • 2 609 932 246 • 03.07

Bosch PSB 500 Specifications

General

Power	500 W
Max. drilling diameter in concrete	10 mm
Max. drilling diameter in steel	8 mm
Max. drilling diameter in wood	25 mm
Chuck type	Keyless chuck
Chuck capacity	1.5 - 10 mm
Cable length	2.5 m
