f Never use the machine with a damaged ca-
ble. Do not touch the damaged cable and
pull the mains plug when the cable is dam-
aged while working. Damaged cables in-
crease the risk of an electric shock.
Products sold in GB only: Your product is fitted
with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.
Products sold in AUS and NZ only: Use a resid-
ual current device (RCD) with a rated residual
current of 30 mA or less.
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
Intended Use
The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling
in wood, metal and plastic. Machines with elec-
tronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Depth stop*
2 Keyless chuck
3 Button for depth stop adjustment*
4 “Drilling/Impact Drilling” selector switch
5 Thumbwheel for electronic speed preselec-
tion (PSB 750 RCE/PSB 750 RCA)
6 Lock-on button for On/Off switch
7 Rotational direction switch
8 On/Off switch
9 Auxiliary handle*
10 Wing bolt for adjustment of auxiliary handle*
11 Extraction device with dust collector*
12 Dust collector*
13 Level indicator of the dust collector
14 Thumbwheel for speed preselection
(PSB 650 RE/PSB 6500 RE/PSB 650 RA)
15 Release button for dust collector*
16 Filter element (micro filtersystem)*
17 Rubber gasket for dust collector *
18 Dust protection ring*
19 Release button for extraction device*
20 Clamp for extraction device*
21 Locking latch for dust collector*
22 Universal bit holder*
23 Screwdriver bit*
24 Spindle lock button
(PSB 650 RE/PSB 6500 RE/PSB 650 RA)
25 Allen key **
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
**Commercially available (not included in the deliv-
ery scope)
OBJ_BUCH-911-002.book Page 20 Monday, September 7, 2009 1:08 PM

Bosch PSB 650 RE Specifications

General

Soft grip	Yes
Input power	650 W
Output power	338 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Torque (max)	9 N⋅m
Idle speed (max)	50 RPM
Impact rate (high speed)	48000 bpm
Drilling diameter in wood (max)	30 mm
Drilling diameter in steel (max)	12 mm
Drilling diameter in concrete (max)	16 mm

Weight and Dimensions

Weight	1700 g
