2 609 005 062 | (16.5.11) Bosch Power Tools
Delivery Scope
Cordless Drill/Driver.
Battery, application tools and other accessories shown or de-
scribed are not part of the standard delivery scope.
A complete overview of accessories can be found in our ac-
cessories program.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic.
Technical Data
The technical data of the machine are listed in the Table on
page 65.
Please observe the article number on the type plate of your
machine. The trade names of the individual machines may
vary.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
18.04.2011
Noise/Vibration Information
The measured values of the machine are listed in the table on
page 65.
Noise and vibrational values (vector sum of three directions)
determined according to EN 60745.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Before any work on the machine itself,
remove the battery
Wear ear protection.
Movement direction
Reaction direction
Right/left rotation
Drilling
Low speed
High speed
Switching On
Switching Off
U Rated voltage
n
0
1 No-load speed (1. gear)
n
0
2 No-load speed (2. gear)
M Maximum torque according to ISO 5393
Metal
Wood
Ø Drilling diameter, max.
Ø Max. screw dia.
Chuck clamping range
Weight according to EPTA-Procedure
01/2003
L
wA
Sound power level
L
pA
Sound pressure level
KUncertainty
a
h
Vibration total value
Symbol Meaning
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
