7. Sawdust blower device switch
8. Guide roller
9. Saw blade
a)
10. Viewing window for Cut Control
a)
11. Base for Cut Control
a)
12. Shock protection guard
13. Handle (insulated gripping surface)
14. Saw blade receptacle
15. Anti-splinter guard
a)
16. Accessory holder
17. Bracket for guide roller
18. Base plate screw
19. Scale for mitre/bevel angles
20. 0° cut mark
a)
21. 45° cut mark
a)
Accessories shown or described are not included with the product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Article number 3 603 CA0 7.. 3 603 CA0 7.. 3 603 CA0 7..
Cut Control ● ● ●
Rated power input W 500 500 500
No-load stroke rate n
0
min
–1
3100 3100 3100
Stroke mm 20 20 20
Max. cutting depth
– in wood mm 65 65 67
– in aluminium mm 10 10 10
– in steel (unalloyed) mm 4 4 4
Max. cutting angle (left/right) ° 45 45 45
Weight according to EPTA-
Procedure 01:2014
kg 1.6 1.6 1.6
Protection class
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in
country-specific models.
