7
Parts List
Refer to Parts List below and on pages 8–10.
• If ANY of the parts are missing,
DO NOT attempt to assemble,
install, or use your router table until the missing parts
have been found or replaced and your router table
has been properly and correctly assembled per this
manual.
• For missing parts or technical assistance,
call 1-877-BOSCH99 (877-267-2499).
• In order to simplify handling and to minimize any
damage that may occur during shipping, your router
table comes mostly unassembled. Note that the
s
witch box and some fasteners are preassembled to
facilitate identification and installation.
• Separate all parts from the packaging materials and
check each part against the illustrations and the parts
lists to make sure that all parts have been included.
Do this before discarding any of the packaging
material.
Key No. Description Quantity
ROUTER TABLE COMPONENTS
1 Router Tabletop 1
2 Router Mounting Plate 1
3 Tabletop Insert w/ 1″ Dia. Hole 1
4 Tabletop Insert w/ 2″ Dia. Hole 1
5 Tabletop Insert w/ 2
3
⁄4″ Dia. Hole 1
6 Table Leg 2
7 Leg Storage Panel 1
8 Leg Cord Wrap Assembly 1
9 Front Fascia Panel 1
10 Switch Box Assembly With Lockout Key 1
10A Lockout Key 1
FENCE COMPONENTS
11 Aluminum Fence 1
12 Fence Facing 2
13 Vacuum Port 1
14 Large Clamping Knob (in hardware bag) 6
15 Overhead Guard 1
16 Spacer (in hardware bag) 6
17 Small Clamping Knob (in hardware bag) 6
18 1/16″ Jointing Shim 2
19 Featherboard 2
STARTER PIN COMPONENTS
20 Starter Pin 1
21 Starter Pin Guard 1
22 #10-32 x 3/8
″ Truss-Head Phillips Machine Screw 1
To Next Page
