82/104 Maintenance and repair
Bosch Rexroth AG, A4... with HS5E pilot control valve/Series 3x, RE 92076-01-B/10.2017
10.5.1 Replacement of components
The replacement of some components of the HS5E control systems is described in
the following.
Accessories for HS5E Material number Data sheet
Plug-in connector, 12-pin for central connection XH4
without cable (assembly kit)
R900884671 08006
Plug-in connector, 12-pin for central connection XH4
with cable set 2 x 5 m
R900032356
Plug-in connector, 12-pin for central connection XH4
with cable set 2 x 20 m
R900860399
Pressure transducer HM 20-2X,
Measuring range 630 bar (4 ... 20 mA)
R901342035 30272
Test device VT-PDFE-1-1X/V0/0 R900757051 29689-B
Compact power supply unit VT-NE32-1X R900080049 29929
An Ethernet M12 to RJ45 connecting cable (ports X7E1 &
X7E2), additional information in type designation RKB0044/
xxx.x (xxx.x: length in meters)
R911172135
General
The product is a sensitive component and must therefore be handled with care. You
must not subject the product to hard impacts and keep it away from magnetic parts!
Until it has been installed in the pump housing, the original packaging is the safest
place to store it.
Size
ASSEMBLY KIT VT-SWA-LIN-1X/G15-1-C20 R901425681 40; 125; 180
ASSEMBLY KIT VT-SWA-LIN-1X/G15-2-C20 R901425682 71
ASSEMBLY KIT VT-SWA-LIN-1X/G15-3-C20 R901425683 250 and larger
Installing the VT-SWA-LIN-...-G15 swivel angle sensor
▶ Tighten the sensor to 25 +
5
Nm (WAF 27).
▶ Tighten the sensor cable on the pilot control valve to 0.6±6% Nm.
▶ Calibrate the swivel angle offset and factor according to chapter8.1.8 "Calibrating
the HS5E control system" on page75.
By quoting the Mat. No. of the pump, you can get seal kits that are either matched to
specific individual components or are a complete package.
The pilot valve is a component that is sensitive to contamination. When replacing it,
make sure that no contaminants enter fluid-carrying parts of the valve and the pump.
Before replacing the new control valve, Bosch Rexroth recommends saving the
parameters of the valve to be replaced and to transfer the data to the replacement
valve.
Accessories
Swivel angle sensor VT-
SWA-LIN-...-G15 for HS5E
systems
Seal kits for the pump
HS5E pilot control valve
