| 63SM Series Heat Pump

6 720 220 406 (2015/02)Revised 02-15

CONSTANT AIRFLOW MOTOR AIRFLOW

TABLE(SM0**-***-***-A)

ECM Const CFM Motor - EON

Models

Fan

Speed

Rated

Airflow

Adjust Tap

External Static Pressure (in of Water)

0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00

SM024

Part Load

Hi 725 + A 725 725 725 725 725 725 725 725 - -

Med 650 Normal A 650 650 650 650 650 650 650 650 - -

Low 500 - A 500 500 500 500 500 500 500 500 - -

SM024

Full Load

Hi 950 + A 950 950 950 950 950 950 950 950 - -

Med 825 Normal A 825 825 825 825 825 825 825 825 - -

Low 725 - A 725 725 725 725 725 725 725 725 - -

SM036

Part Load

Hi 950 + A 950 950 950 950 950 950 950 950 950 950

Med 800 Normal A 800 800 800 800 800 800 800 800 800 800

Low 750 - A 750 750 750 750 750 750 750 750 750 750

SM036

Full Load

Hi 1300 + A 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300

Med 1100 Normal A 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100

Low 950 - A 950 950 950 950 950 950 950 950 950 950

SM048

Part Load

Hi 1400 + A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

Med 1300 Normal A 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300

Low 1100 - A 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100

SM048

Full Load

Hi 1800 + A 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800

Med 1600 Normal A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

Low 1400 - A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

SM060

Part Load

Hi 1800 + A 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800

Med 1600 Normal A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

Low 1400 - A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

SM060

Full Load

Hi 2200 + A 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200

Med 2000 Normal A 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000

Low 1800 - A 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800

SM070

Part Load

Hi 2100 + A 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100

Med 1850 Normal A 1850 1850 1850 1850 1850 1850 1850 1850 1850 1850

Low 1600 - A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

SM070

Full Load

Hi 2500 + A 2500 2500 2500 2500 2500 2500 2500 2500 2500 2500

Med 2350 Normal A 2350 2350 2350 2350 2350 2350 2350 2350 2350 2350

Low 2100 - A 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100

Brand	Bosch
Model	SM024
Category	Heat Pump
Language	English

Bosch SM024 User Manual
